We are committed to offer best quality products and competitive prices. With our pioneering spirit, Bida can provide mature solutions and give you the competitive edge. Our engineers are available to service machinery overseas. Any Questions Just Call +86-13855170365.
| Place of Origin | Anhui ,China |
| Brand | Bida |
| Shipping Port | Any port in China |
| Free Maintenance | One Year |
| Lead Time | About 3 Weeks |
PRODUCT DESCRIPTION
Use infrared camra with advanced InGaAs material,not only can sort the material by color,but also can sort other impurities with same color, like, plastic, stone, insect, glass, wormhole, shell, metal and etc. Advanced Micro Processing Technology + ARM + DSP + Black-Tech + IOT extremely increases the sorting capacity to ensure your high producing ability. Latest technology of LED system can satisfy thousands of colors identification, separation and classification requirements.
Data Synchronization System makes the adjustment work into the way of ONE BUTTON OPERATION. Latest ejector technology makes the ejectors longer life time, lower air consumption, faster speed, easier maintenance and high sorting accuracy. Special feeding system design makes each chutes separated and allows you to combine the chutes due to sorting requirements, decreases the rejection ratio and air consumption.
Self-checking system makes the machine can check the ejectors, cameras, control boards and background boards automatically and save your time to check all components and parts every time before operation. No wearing parts(except mine stone color sorter) makes 0 maintenance cost.
SORTER PARAMETERS
| Model | BDG1 | BDG2 | BDG3 | BDG4 | BDG5 | BDG7 | BDG10 | BDG16 |
| Throughput（T/H) | 0.1-0.6 | 0.3-2 | 0.5-3 | 1-4 | 1.5-5 | 2-7 | 3-8 | 5-15 |
| Accuracy（%） | ≥99.99 | ≥99.99 | ≥99.99 | ≥99.99 | ≥99.99 | ≥99.99 | ≥99.99 | ≥99.99 |
| Optimal Reject Rate | ≥20:1 | ≥20:1 | ≥20:1 | ≥20:1 | ≥20:1 | ≥20:1 | ≥20:1 | ≥20:1 |
| Weight（KG） | 340 | 470 | 600 | 740 | 900 | 1220 | 1700 | 2100 |
| Power（KW） | 0.7 | 1.1 | 1.4 | 1.8 | 2.2 | 3.0 | 4.2 | 6.8 |
| Dimension (L×W×H)(MM) |
890*1500 *1300 |
1200*1500 *1460 |
1860*1500 *1420 |
1970*1500 *1420 |
2300*1600 *1360 |
3200*1550 *1350 |
3850*1550 *1420 |
3480*2850 *2050 |
| Air Pressure（MPa） | 0.6-0.8 | 0.6-0.8 | 0.6-0.8 | 0.6-0.8 | 0.6-0.8 | 0.6-0.8 | 0.6-0.8 | 0.6-0.8 |
| Air Consumption（m³/min） | 0.1-0.4 | 0.3-0.8 | 0.5-1.2 | 0.8-1.6 | 1.0-2.0 | 1.5-2.5 | 2.0-4.0 | 3.0-7.0 |
| Voltage | 220V/50Hz | 220V/50Hz | 220V/50Hz | 220V/50Hz | 220V/50Hz | 220V/50Hz | 220V/50Hz | 220V/50Hz |
| Note: Above sorting parameters is calculated on 2% contamination soybeans for reference only. | ||||||||
